Quicseal 613

QUICSEAL 613 EPOXY GROUT

QUICSEAL 613 EPOXY GROUT is a three-component epoxy resin-based product mixed with silica sand and special additives, designed to create a bonding paste with high adhesion strength. This epoxy grout is known for its versatility and chemical resistance, making it suitable for various wall and floor applications.

Typical Uses:

• Internal and external areas with various types of tiles (ceramic, homogenous, quarry, etc.)
• Areas exposed to chemical contact, such as in dairies, breweries, food and chemical industries, and swimming pools.
• Areas subjected to heavy traffic, such as walkways and pavements.

Advantages:

• Available in multiple colors.
• Good chemical resistance.
• Excellent abrasion resistance.
• Excellent water resistance.
• Water cleanable.

Substrate Preparation:

The substrates must be clean and sound, free of dust, loose particles, laitance, oil, grease, and other contaminants. For concrete surfaces, any curing compound must be removed using appropriate methods.

Technical Data:

• Product Type: Solvent-free epoxy-based
• Colour: Standard colors available
• Density of Mix: 1.88 ± 0.06 g/ml
• Consistency of Mix: Pasty
• Pot Life: Approximately 30-50 mins at 25°C
• Ready for Traffic: After 24 Hours
• Bond Strength to Concrete (ASTM D4541):
  • @ 1 day: > 3.0 MPa (cohesion failure within concrete)
  • @ 7 days: > 3.5 MPa (cohesion failure within concrete)
• Compressive Strength (ASTM D695): 60 ± 5 MPa
• Chemical Resistance:
  • 18% Hydrochloric Acid: Good
  • Sodium Hydrochloride: Excellent (13% (m/m) of active chloride)
• Ratio by weight (A:B:C): 1.0 : 0.6 : 4.4

Preparing the Mix: Mix QUICSEAL 613 (Part A) and Part B together thoroughly, then add QUICSEAL 613 Part C and mix until a homogeneous paste is achieved.

Grouting Tile Joints: Apply the paste with a hard rubber trowel, fill joints completely, and remove excess paste. Rinse with clean water after excess grout removal. Allow at least 24 hours before foot traffic.

Cleaning: Clean tools and hands immediately after application. After setting, cleaning can only be done by mechanical means.

Coverage: For grouting tile joints, consumption depends on tile dimensions and joint width.

Packaging: QUICSEAL 613 is supplied in a 6kg set.

Storage: Store in a cool and ventilated place in the original packaging for up to 12 months.
