MasterFlow 810 – Non-shrink, cementitious grout for use in general civil engineering works

DESCRIPTION

MasterFlow 810 stands as a ready-to-use, non-shrink, cementitious grout featuring natural aggregates, tailored for general civil engineering applications. This grout offers an extended working life coupled with high early and ultimate strengths.

FIELDS OF APPLICATION

MasterFlow 810 is well-suited for various purposes including:

Stanchion baseplates and columns
Prefabricated concrete panels and beams
Bridge bearing plates
Anchor bolts and bars
Underpinning
Patch repair works

FEATURES AND BENEFITS

High Strength: Provides impressive early and long-term strengths for quick return to service and enduring durability.
Non-Shrink: Hardens devoid of bleeding, settlement, or drying shrinkage when placed at a flowable consistency.
Flowable Consistency: Ensures thorough filling of intricate voids, often eliminating the need for pumping and strapping.
Extended Working Time: Remains placeable for up to an hour, even in high ambient temperatures.
Dense, Impermeable Grout: Creates a strong watertight seal.
Economical: Allows for handling greater grout volumes with reduced labor.
Ease of Use: Requires no specialized mixing equipment; a pail and grout stirrer are sufficient.
No Added Chloride: Does not contribute to chloride loads on structures.
Complete Non-Shrink Performance: Demonstrates non-shrink performance per the simulated Bedplate Technique.
Versatile: Can be placed in a range of consistencies from flowable to trowelable.

PROPERTIES

Compressive Strength:
- Flowable: 25 N/mm2 (1 day) to 65 N/mm2 (28 days)
- Trowelable: 45 N/mm2 (1 day) to 85 N/mm2 (28 days)
Setting Time:
- Initial: 5:30 hours
- Final: 6:30 hours
Supply Form: Powder
Colour: Cement Grey
Water Addition:
- Flowable: 18%
- Trowelable: 12.8–13.6%
Density:
- Flowable: 2.18 kg/L
- Trowelable: 2.26 kg/L
Flow Through (Flowable): 35–55 cm

APPLICATION

MasterFlow 810 can be mixed to flowable or trowelable consistency. Water quantity for a 25 kg bag varies between 4.5 liters (flowable) and 3.2–3.4 liters (trowelable). Water addition may be influenced by on-site temperature conditions; trials are recommended for accuracy.

Mixing should continue until the grout achieves a smooth, lump-free appearance. Best results are attained within 30 minutes of mixing. Adequate substrate preparation, saturation with water, and proper curing are crucial. Cleaning tools with water before hardening is essential.

ESTIMATING DATA

A 25 kg bag of MasterFlow 810 yields approximately 13.5 liters of flowable grout and 12.5 liters of trowelable grout.

PACKAGING & SHELF LIFE

Packaged in 25 kg multi-ply paper sacks, MasterFlow 810 has a shelf life of approximately 12 months when stored in a cool, dry, unopened environment.

PRECAUTIONS

Detailed health, safety, and environmental instructions can be found in the product’s Material Safety Data Sheet (MSDS) available from the manufacturer’s office or website.
