Sikabit Pro P-40-0 Mg

SIKABIT PRO P-40-0 MG – PLASTOMERIC MODIFIED BITUMINOUS WATERPROOFING MEMBRANE

DESCRIPTION

SikaBit PRO P-40-0 MG is an advanced waterproofing membrane, featuring APP modification and torch application for a secure, long-lasting seal. It is reinforced with a dimensionally stable non-woven polyester inlay, ensuring it can stand up to the most demanding conditions. With a thin polyethylene burn-off film on the underside, this membrane is incredibly easy to apply. The top surface is finished with mineral granules, adding an extra layer of durability. Its thickness of approximately 4.0 mm makes it the perfect choice for your waterproofing needs.

APPLICATION

The versatility of SikaBit PRO P-40-0 MG shines through in its numerous applications:

• Retaining walls and basements: Protect these critical structures from water damage.
• Flat roofs under protective layers or ballast: Ensure a water-tight seal for flat roofs, whether under protective layers or ballast.
• Balconies and terraces under tiles: Keep your outdoor spaces dry and intact.
• Wet rooms: Prevent water from seeping into your interiors.
• Underground car parks: Preserve the integrity of underground structures.
• Raft slabs: Ensure that water won’t compromise your concrete slabs.
• As a top sheet in a double layer roofing system: Utilize it as a top sheet for double-layer roofing systems.
• Protection of various substrates in a wide range of applications: Count on it to safeguard various substrates in a multitude of construction scenarios.

ADVANTAGES

SikaBit PRO P-40-0 MG offers a plethora of advantages that set it apart:

• Good watertightness: With this membrane in place, you can trust that your structure will remain dry.
• Good elongation and cold flexibility: It adapts to temperature changes, ensuring a lasting seal.
• Good mechanical properties: It offers excellent tensile, tear, and shear strength.
• Good resistance to impact: Even under harsh conditions, this membrane holds its own.
• Easy installation by torching method: Save time and labor with its simple installation process.
• Choice of primers: SikaBit PRO P-40-0 MG gives you the flexibility to choose the right primer for your specific substrate and weather conditions.

PRODUCT INFORMATION

• Composition: APP modified bitumen
• Reinforcing Material: Non-woven polyester fabric
• Packaging: Roll size
  • Length: 10.00 m
  • Width: 1.00 m
• Appearance / Colour: Top surface Mineral granules
• Backing: Polyethylene film
• Shelf life: 12 months from the date of production

To ensure its longevity, store this product in its original, unopened, and undamaged sealed packaging in dry conditions and temperatures between +5°C and +35°C. Keep it in a vertical position and avoid stacking pallets of rolls on top of each other during transport or storage.

TECHNICAL SPECIFICATIONS

Here are the technical specifications of SikaBit PRO P-40-0 MG:

Property	Value
Resistance to Impact	≥ 600 mm at +23°C (EN 12691- Method A)
Tensile Strength	Longitudinal 600 N/50 mm ± 20%
	Transversal 400 N/50 mm ± 20%
Elongation	Longitudinal 30% ± 15%
	Transversal 30% ± 15%
Tear Strength	Longitudinal 150 N ± 30%
	Transversal 150 N ± 30%
Joint Shear Resistance	Longitudinal Min. 500 N/50mm
	Transversal Min. 350 N/50mm
Flow Resistance	≥ 120°C (EN 1110)
Watertightness	60 kPa (EN 1928-Method B)

CONSTRUCTION INSTRUCTIONS

Proper installation of the SikaBit PRO P-40-0 MG waterproofing membrane is crucial to ensure the long-term performance and water-tightness of your construction project. Follow these detailed construction instructions to achieve a successful application:

SUBSTRATE QUALITY

• Structural Strength Assessment: Before beginning the installation, ensure that the supporting structure is of sufficient structural strength to support all new and existing layers of the waterproofing build-up. In the case of roofing applications, the entire roof system must be designed to withstand wind uplift loadings.
• Substrate Preparation: The substrate surface should be uniform, firm, smooth, and free of any sharp protrusions, burrs, grease, bitumen, oil, dust, or loosely adhering particles. Utilize appropriate preparation equipment to achieve the desired substrate quality.

APPLICATION METHOD / TOOLS

• Priming: Proper priming is crucial to ensure adhesion. Apply the appropriate primer from the SikaBit P or Sika® Igolflex P range to the prepared dry surface. Follow the consumption rate recommendations for the primer and allow it to dry completely before proceeding to the next application stage. Refer to the individual Product Data Sheets for specific primer instructions.
• Alignment: Unroll the SikaBit PRO P-40-0 MG membrane and carefully align it with the intended application area. Re-roll the membrane correctly to ensure proper positioning before torching.
• Overlaps: Maintain the recommended overlap measurements to create a secure and water-tight seal. For side overlaps, ensure an overlap of 80 mm, and for end overlaps, maintain a minimum of 150 mm.
• Torching: Use a gas burner to heat both the substrate and the backing film on the underside of the membrane. As the backing film begins to melt, the membrane is ready to adhere. Roll the membrane forward, pressing it firmly against the substrate to create a strong bond.
  • Safety Note: Be cautious not to over-torch the membrane, as excessive heat can damage the polyester reinforcement, making the membrane un-useable.
• Detailing: Pay special attention to all details, including internal and external corners, upstands, vent pipes, drains, and support metalwork. Each of these areas should be cut and sealed effectively to maintain a water-tight seal. Always follow the recommended guidelines and best practices for torch-applied membranes when working on details.
• Protection: Throughout the construction process, take measures to protect the installed membrane from potential damage. Ensure that ongoing site activities do not compromise the integrity of the membrane.

MAINTENANCE

To preserve the functionality of the waterproofing membrane during its lifespan, regular maintenance and inspection are essential. Consider the following:

• Periodically inspect the membrane and detailing to ensure their continued functionality.
• Check the functionality of auxiliary components such as flashings, drainage outlets, overflow pipes, and remove any debris like leaves, moss, or vegetation that may accumulate.

IMPORTANT CONSIDERATIONS

• In low-temperature conditions, take care when unrolling the membrane to avoid damaging it.
• Use appropriate footwear to prevent puncturing the membrane during installation.
• Avoid applying the membrane to wet, damp, or unclean surfaces.
• Ensure you do not over-torch the membrane, as this can damage the polyester reinforcement.
• If the membrane is insufficiently heated, it can lead to reduced adhesion to the substrate, between layers, or on the overlaps. In such cases, un-bonded areas must be lifted and re-torched.
• If a seasonal symbol is printed on the roll’s label, it is advisable to use the membrane during the indicated season.

By adhering to these detailed construction instructions, you can ensure that SikaBit PRO P-40-0 MG is installed correctly and effectively, providing long-lasting water-tightness and protection for your construction project. Always consult the most up-to-date product documentation and guidelines for specific details and conditions.
