BITUSTIK – Self-Adhering Waterproofing Membrane

Description:

BITUSTIK is a self-adhering waterproofing membrane made of distilled bitumen modified with SBS (styrene-butadiene-styrene) polymers. It features an adhesive coating on the lower face and a self-protecting upper surface with either sand (BITUSTIK 2.0 mm) or plastic PE film (BITUSTIK 1.5 mm).

The carrier is a composite polyester stabilized with longitudinal glass yarns, providing superior dimensional stability, good tensile strength, elongation values, and excellent mechanical properties.

Available Surface Finishes:

Upper Surface: Sand (BITUSTIK 2.0 mm) or plastic PE film (BITUSTIK 1.5 mm).
Lower Surface: Silicone release film.

Storage: Store in a dry, cool place away from direct sunlight and frost.

Use For: BITUSTIK is recommended as an underlayer in multilayer systems or as a waterproofing layer below roof tiles or on pitched roofs where the use of an open flame is not permitted or advisable. This is particularly useful over wooden decks or fire-sensitive insulation layers. BITUSTIK offers a fast and safe application, saving time during the waterproofing process.

Health and Safety Information:

Ecology: According to local law.
Transportation: Non-hazardous.
Toxic: Non-toxic.

Technical Information:

Properties	Test Method	Unit	BITUSTIK 1.5mm	BITUSTIK 2.0 mm	TOL
Length	EN 1848-1	m	20.0 (-1%)	20.0 (-1%)	≥
Width	EN 1848-1	m	1.0 (-1%)	1.0 (-1%)	≥
Thickness	EN 1849-1	mm	1.5	2.0 ± 5%
Tensile Strength L/T (max load)	EN 12311-1	N/5cm	400/300	400/300	±20%
Breaking Elongation L/T	EN 12311-1	%	35/35	35/35	±15
Resistance to Tearing L/T	EN 12310-1	N	130/130	130/130	±30%
Resistance to Static Loading	EN 12730 (A)	kg	10	10	≥
Impact Resistance	EN 12691	mm	700	700	≥
Dimensional Stability	EN 1107-1	%	±0.3	±0.3	≤
Flexibility at Low Temperature	EN 1109	°C	-15	-15	≤
Flow Resistance at Elevated Temp.	EN 1110	°C	90	90	≥
Watertightness (A method)	EN 1928	kPa	60	60	≥
Water Vapour Transmission	EN 1931	μ	20,000	20,000	≥
Reaction to Fire	EN 13501-1	Class	E	E	–
External Fire Exposure Behavior	EN 13501-5	Class	F Roof	F Roof	–

Note: The information provided is based on technical specifications. For actual use, it is recommended to follow the application guidelines and best practices provided by the manufacturer.
